Standard Specification for Spectrum 480 Pilothouse



                                                                                     Overall Length: 4.8 M                                                                                 Beam: 2.09 M

           Freeboard: 26inches
                                                           Maximum engine size: 60 hp

                 Design Category: C

                             Maximum persons capacity: 5 (375 kg max.)

                                           Typical weight: 440kg

Personal effects and tackle: 175 kg

  Height on trailer (approx) 2.8M



Cabin measurements

Max length 200 cm

Max width 180 cm
Height from floor 125 cm
Height from mattress 95 cm


Hull design

The modern white hull makes for a clean look and is designed for excellent sea-keeping qualities. Combining a smooth ride with stability. A defined V and reasonably flat bottom with skeg to the stern reduces “weave” at low speeds. Spectrum’s moulded non-slip deck system on all tread areas. Navigation lights.



Buoyancy:

The under-floor buoyancy chamber is foam-filled to give buoyancy.


                                   Cockpit

The generous cockpit makes the Spectrum 480 ideal for fishing, diving, and family fun. Furnished with high quality vinyl cushions for all seating. A removable side bench seat creates even more deck space. The cockpit has 2 self-draining points as well a electric bilge pump below deck.



Windows:

The windows are polycarbonate and are fastened with stainless steel screws to resist wave impact, an essential feature for seaworthiness.


Steering System

The Spectrum 480 is equipped as standard with top quality, Teleflex Negative feedback steering system, No Feedback is a built into the helm which locks out steering loads caused by propeller torque thus minimizing the effects of the feedback and minimizing the effort on the operator to steer the boat and with a comfortable 5 spoke padded steering wheel.


Deck

Deep anchor locker to the bow with drainage. Two heavy duty stainless steel stern cleats are provided in addition to the foredeck mooring Cleat. Non slip gelcoat deck.



Grab Rails:

The standard equipment includes full-length stainless steel grab rails to both sides of the cockpit and a full pulpit to the bow of the boat.


Cabin

Inside the cabin there is a comfortable place for crew to shelter from the weather or to have the occasional night's sleep. Cushions are supplied as standard, and they can be colour coordinated with the hull of the boat. Anodised aluminium framed and glazed front hatch to provide more light and ventilation into the cabin.


           Colour Options

Available in many colourways with a choice of interior upholstery colours.
